ZuluSCSI RP2040 Compact - Adaptador SCSI a SD

¡Nueva versión RP2040 Compact! Usa una SD con tu controladora SCSI. Este adaptador te permitirá usar una tarjeta SD en lugar de un dispositivo SCSI real. Compatible con una gran variedad de controladoras SCSI. Incluyendo las de las placas base de Amiga, controladoras de terceros fabricantes como la A590 o la Blizzard/Cyberstorm SCSI, Atari, Apple, PC, samplers, máquinas CNC, instrumental científico, etc. El adaptador para bahía de 3,5" está disponible como opción.

Más detalles

Referencia:
59-SCSI-SD-zulu-2-2040
Cantidad
Disponibilidad:
En stock

79,95 € IVA incl.

Usa una tarjeta SD con tu controladora SCSI.

Este adaptador te permitirá usar una tarjeta SD en lugar de un dispositivo SCSI real. Compatible con una gran variedad de controladoras SCSI. Incluyendo las de las placas base de Amiga, controladoras de terceros fabricantes como la A590 o la Blizzard/Cyberstorm SCSI, Atari, Apple, PC, samplers, máquinas CNC, instrumental científico, etc.

ZuluSCSI emulates a SCSI-I or SCSI-2 hard drive using an SD memory card. Each ZuluSCSI purchase includes a fully assembled and tested circuit board, ready for use. It is a new generation of file-based SCSI HDD & CD-ROM emulators, and represents a fusion of SCSI2SD V5, V6, and BlueSCSI. Hard drive and CD-ROM drive images are stored on a standard FAT32 or exFAT-formatted SD card. New RP2040 version supports synchronous and asynchronous transfer modes with read speeds up to eight megabytes/second. A SCSI controller with FAST SCSI and synchronous mode is required to achieve maximum speeds.

 ZuluSCSI

Features:

• Read/Write speed: 8Mb/ss
• Supports synchronous and asynchronous transfer modes
• Powered by the Raspberry Pi Foundation's RP2040 microcontroller, a dual-core 133MHz ARM Cortex-M0+ processor
• SCSI Termination is DIP-switch controlled
• Emulates up to 7 SCSI devices simultaneously, including CD-ROM
• Firmware upgrade simplicity; As easy as placing a file on the SD card
• Firmware recovery mechanism provided
• Highly configurable using a text-based ini file, ZuluSCSI.ini
• Designed to be powered via SCSI termination power, when provided by the host
• Also powered via standard Berg connector (floppy style)
• External LED connector (pins not assembled)
• Sector size (can also be set via the SCSI MODE SELECT command, as sent by SCSI format utilities)
• 74LVTH125 SCSI bus transceivers, as used in SCSI2SD V5 and SCSI2SD V6 Rev F
• SCSI command implementations are from SCSI2SD
• Uses the same SCSI command handling code as SCSI2SD V6, compatibility with nearly all devices that speak both SCSI-1 and SCSI-2 is extremely high
• Identical dimensions and mounting holes as that of SCSI2SD V5.1, V5.2, and V6, making it compatible with many existing SCSI2SD-specific mounting solutions

Please, find the online ZuluSCSI manual here and a list of compatible devices here.

Warranty: 3 years.
Manual: not included.
